EF/EL vs EB/ED intake manifold



Page 1 of 1 [ 5 posts ]


 Post subject: EF/EL vs EB/ED intake manifold
Posted: Mon Jul 12, 2010 2:14 pm
Getting Side Ways
Offline

Age: 29

Posts: 2563

Joined: 19th Feb 2007

Gallery: 21 images

Ride: 98 EL Futura

Power: 199 rwkw

Location: Lilydale
VIC, Australia

Gday

Im just wondering what peoples thoughts are on them?
From what iv read and seen with dyno charts the EF/EL gains a little more torque through the low-mid range. I have also seen people switch there manifolds on the EF/EL back to the EB/ED manifold and are pulling big numbers.

Do you think there is a certain point where the BBM restricts in the high rev range?



_________________

EL Futura: CVE head, Wolf V500, ICE Ignition and Coil, 36lb injectors, Walbro 255lb, Paci comps, 3" exhaust, T5, Harrop Truetrac with 3.9s. Now with 198.9rwkw, (~185rwkw and 13.80 @99.1mph) with more power to come

Top
 Profile


 Post subject: Re: EF/EL vs EB/ED intake manifold
Posted: Mon Jul 12, 2010 3:00 pm
Getting Side Ways
Offline

Posts: 5582

Joined: 20th May 2005

Gallery: 11 images

Ride: EB1 Fairmont Ghia T5 Wagon

Location: Seven Hills, Sydney
NSW, Australia

Common workshop/backyard theory is that the EB-ED log manifold is better for high rpm figures.

The BBM might loose a RWKW or two at max rpm, but gives huge gains in the midrange in comparison.

This old dyno of the same engine fitted with both manifolds pretty much explains it.


Cheers
BenJ



_________________

BenJ's EB T5 DOHC Ghia Wagon - Current Ride
BenJ's EB GL Sedan - Previous Ride
My respect and thanks go to - snap0964, Paulmac, SWC and MRE-50L

Top
 Profile


 Post subject: Re: EF/EL vs EB/ED intake manifold
Posted: Mon Jul 12, 2010 3:02 pm
Getting Side Ways
Offline

Age: 29

Posts: 2563

Joined: 19th Feb 2007

Gallery: 21 images

Ride: 98 EL Futura

Power: 199 rwkw

Location: Lilydale
VIC, Australia

Cheers BenJ

thats what I was looking for, is this why many people use the old style one for turbo setups as well? keep the flow all the way to redline?



_________________

EL Futura: CVE head, Wolf V500, ICE Ignition and Coil, 36lb injectors, Walbro 255lb, Paci comps, 3" exhaust, T5, Harrop Truetrac with 3.9s. Now with 198.9rwkw, (~185rwkw and 13.80 @99.1mph) with more power to come

Top
 Profile


 Post subject: Re: EF/EL vs EB/ED intake manifold
Posted: Mon Jul 12, 2010 3:19 pm
Getting Side Ways
Offline

Posts: 5582

Joined: 20th May 2005

Gallery: 11 images

Ride: EB1 Fairmont Ghia T5 Wagon

Location: Seven Hills, Sydney
NSW, Australia

Many choose to use the Log manifold for boosted applications, as runner length has no impact on performance when under boost. From the factory, BA turbos had the runner valves removed from the BBM.

In addition the location of the throttle body makes intercooler piping much simpler and easier to route.

I noticed a large improvement in the mid range torque in my Wagon when I installed the BBM. This made for a much better daily drive. Most of your day to day use is the mid range, with the occasional spurt to 5grand or more.

It will come down to what you want from your own car.

Cheers
BenJ



_________________

BenJ's EB T5 DOHC Ghia Wagon - Current Ride
BenJ's EB GL Sedan - Previous Ride
My respect and thanks go to - snap0964, Paulmac, SWC and MRE-50L

Top
 Profile


 Post subject: Re: EF/EL vs EB/ED intake manifold
Posted: Mon Jul 12, 2010 7:06 pm
Getting Side Ways
Offline
User avatar

Age: 49

Posts: 6467

Joined: 18th Dec 2006

Ride: 93 ED sedan

Power: 161 rwkw

Location: Rockhampton
QLD, Australia

This is my torque curve...ED 4.0 sedan, 5sp man, log maifold.
It is std apart from head work and exhaust..., no cam, v/springs, no oversize valves, no raising compression.
The run was done on a hot day of 32*C and 68% humidity.





Attachments:
IMGP3994.JPG [ 294.77 KiB | Viewed 132 times ]



_________________

http://youtu.be/jJTh9F3Vgg0
