Pottential Major fix for E series bad idle Problems



Page 1 of 1 [ 8 posts ]


 Post subject: Pottential Major fix for E series bad idle Problems
Posted: Sat Jan 12, 2008 12:38 pm
Getting Side Ways
Offline
User avatar

Age: 30

Posts: 3737

Joined: 22nd May 2006

Ride: BF F6 Tornado - #0077

Location: Bendigo
VIC, Australia

Started off i had to take the rocker cover off ages ago. 3 weeks later i replaced the oxy sensor and reset the ecu. the next day the car did some really wierd stuff at start up and was stalling out all over the place.

it got better after a while (days) and couldnt put a finger on it.

i replaced the dissy, coil, leads, plugs, map (borrowed) and a few other things and couldnt find it. and the bank account was down $700

get under the bonnet thismorning and start checking the vac lines again. pulled the 2 inch line off the fuel pressure regulator and sucked on it to see it it held. the thing has a huge gash in it where it meets to the nipple. couldnt even see it till i stretched the pipe.

new pipe on and the car seems to be behaving its self well. an improvment, but not perfection yet.

wondering how many other people have unwittingly got this problem? i got a feeling this may be a REALLY common problem as the line isnt a great size for the job its needed for.



_________________

** For Sale ** http://www.fordmods.com/ford-parts-for-sale-f17/assorted-e-series-parts-t124697.html

F6 Tornado 2006 Build

Is it about sex? The engine in my car? Or a cure for cancer?
No?

Then f**k off

Top
 Profile


Posted: Sat Jan 12, 2008 2:53 pm
Getting Side Ways
Offline

Age: 30

Posts: 1087

Joined: 1st Sep 2007

Ride: '07 LT XR5

Power: 133 rwkw

Location: sydney
NSW, Australia

if you reset the ECU the car will run like crap for a week or so, you have to teach it how to behave again, hence the stalling



_________________

So much RAM the motherboard twisted off the POST.

I lost 3 cylinders... but gained a turbo...
Proud owner of an '07 XR5Turbo

Top
 Profile


Posted: Sat Jan 12, 2008 2:56 pm
Getting Side Ways
Offline

Posts: 6166

Joined: 8th May 2007

yep, i recently inspected all the hoses, and fair enough the rubber hose on top of the regulator had a big hole where it comes off the metal fitting.

So i bought and cut off a longer piece so it wasnt on such an angle as before. Ive heard the car can run lean with that hose damaged?
Top
 Profile


Posted: Sat Jan 12, 2008 3:22 pm
Getting Side Ways
Offline

Age: 50

Posts: 504

Joined: 2nd Dec 2006

Ride: EF wagoon

Location: perth
WA, Australia

anyone got as picture of the offending hose, for us dummies that don't know which one you speak of. :D



_________________

EF GLi Wagoon
Grandpa Spec

Top
 Profile


Posted: Sat Jan 12, 2008 3:25 pm
Getting Side Ways
Offline

Posts: 6166

Joined: 8th May 2007

remove the intake, and look at the end of the fuel rail at the firewall. You will see a round u.f.o. looking thing with a hose coming off the top off it.
Top
 Profile


Posted: Sun Jan 13, 2008 10:40 pm
Getting Side Ways
Offline

Age: 70

Posts: 657

Joined: 24th Sep 2007

Gallery: 10 images

Location: Central Coast
NSW, Australia

This is of a log manifold setup, but you should recognize it on a BBM engine.
Paul





Attachments:
File comment: The red arrow, fuel pressure reg & hose
IMG_0169a (Small).jpg
IMG_0169a (Small).jpg [ 179.28 KiB | Viewed 67 times ]



_________________

What goes around, comes around.

Top
 Profile


Posted: Sun Jan 13, 2008 10:45 pm
Getting Side Ways
Offline
User avatar

Age: 30

Posts: 3737

Joined: 22nd May 2006

Ride: BF F6 Tornado - #0077

Location: Bendigo
VIC, Australia

pugsley wrote:
anyone got as picture of the offending hose, for us dummies that don't know which one you speak of. :D


green is the injector rail. red is where it is (on the end of the rail) it looks like a very small version of the blue circled object. has a 5mm piece of rubber on top going to the brake booster line. check ALL your vac lines to see if they hold pressure. the diaphram could also be punchered, suck on the line while the engines running. any strong smell / taste of fuel and it needs replacing.





Attachments:
File comment: fuel pressure reg
DSCF0940.JPG [ 279.9 KiB | Viewed 64 times ]



_________________

** For Sale ** http://www.fordmods.com/ford-parts-for-sale-f17/assorted-e-series-parts-t124697.html

F6 Tornado 2006 Build

Is it about sex? The engine in my car? Or a cure for cancer?
No?

Then f**k off

Top
 Profile


Posted: Sun Jan 13, 2008 10:48 pm
Getting Side Ways
Offline
User avatar

Age: 30

Posts: 3737

Joined: 22nd May 2006

Ride: BF F6 Tornado - #0077

Location: Bendigo
VIC, Australia

Paulmac wrote:
This is of a log manifold setup, but you should recognize it on a BBM engine.
Paul


i think it looks a lot different to that. but i cant remember



_________________

** For Sale ** http://www.fordmods.com/ford-parts-for-sale-f17/assorted-e-series-parts-t124697.html

F6 Tornado 2006 Build

Is it about sex? The engine in my car? Or a cure for cancer?
No?

Then f**k off

Top
 Profile
