At night they worked really well. However I did do it differently to most to get it to look that good at night.

I made up a sandwich of the face layer on top, a transparency layer with a black set of guages with only the markings allowing light through, and the bottom layer was made from frosted plastic with the relevant holes cut in all layers.

BenJ



_________________

BenJ's EB T5 DOHC Ghia Wagon - Current Ride
BenJ's EB GL Sedan - Previous Ride
My respect and thanks go to - snap0964, Paulmac, SWC and MRE-50L

Top
 Profile


Posted: Mon Aug 11, 2008 6:03 pm
Fordmods Newbie
Offline

Posts: 5

Joined: 10th Aug 2008

Ride: XG

Location: Queanbeyan
NSW, Australia

Wow........ must of taken a while... nice job. Got an idea of using uv paint and changing all the dial/main dash globes to black /uv lights... see how it goes..
Top
 Profile


Posted: Tue Aug 12, 2008 12:49 am
Getting Side Ways
Offline
User avatar

Posts: 2943

Joined: 24th Jan 2005

Gallery: 18 images

Ride: XW, EL, Territory, VFR800

Power: 129 rwkw

Location: Adelaide
SA, Australia

Finally got round to giving this a go...

3 hours later... (1 hour of that was spent re-learning Photoshop :lol: )




Doesn't look like I did much but I'm thinking "less is more!"

I made the Carbon Fibre pattern myself :) and fiddled with the FPV logos for ages til I got a good one.

What do you think?!
