How to identify if a BA has an LSD!



Page 1 of 1 [ 10 posts ]


 Post subject: How to identify if a BA has an LSD!
Posted: Mon May 31, 2010 5:04 pm
Getting Side Ways
Offline
User avatar

Age: 33

Posts: 930

Joined: 6th Nov 2004

Ride: EB SXR6 | ED XR8 Sprint

Location: Sydney
NSW, Australia

I just bought a BA XR6 over the weekend, i have a picture that has no reference to the question im about to ask but i thought you may like to see it! (yes its the BA that was on ebay)

ANYWAY how do i find out if it has an LSD? the a** swings out a little when i give it out of a corner but nothing like my eb xr6, so i wasnt sure. I am wondering if it should say anything on the plates or in the log books, or if there is a sticker like the older models some where on the diff?..

thanks!





Attachments:
car1.jpg [ 19.93 KiB | Viewed 5305 times ]



_________________

EB SXR6. ED XR8 Sprint.

Top
 Profile


 Post subject: Re: How to identify if a BA has an LSD!
Posted: Mon May 31, 2010 5:06 pm
Getting Side Ways
Offline

Age: 44

Posts: 577

Joined: 30th Apr 2009

Ride: 92 EB Falcon

put 1 wheel on dirt and the other on the road and spin em if it spins both it has to be lsd
Top
 Profile


 Post subject: Re: How to identify if a BA has an LSD!
Posted: Mon May 31, 2010 5:09 pm
Getting Side Ways
Offline

Age: 44

Posts: 577

Joined: 30th Apr 2009

Ride: 92 EB Falcon

wait before any one posts about how stupid i am maybe this is a bad idea :?
Top
 Profile


 Post subject: Re: How to identify if a BA has an LSD!
Posted: Mon May 31, 2010 5:16 pm
Oompa Loompa
Offline

Age: 24

Posts: 34

Joined: 22nd Apr 2010

Gallery: 2 images

Ride: el futura

Location: tumut
NSW, Australia

there will be a yellow tag on the bottom of the diff with the ratio and weather its lsd or not written on it
Top
 Profile


 Post subject: Re: How to identify if a BA has an LSD!
Posted: Mon May 31, 2010 11:29 pm
ACT Cruise Moderator
Offline
User avatar

Age: 36

Posts: 6275

Joined: 24th Nov 2004

Ride: '06 BF GT-P

Power: 293 rwkw

Location: Canberra
ACT, Australia

Only Turbo's, XR8's and FPVs got LSDs standard, other than that they were optional on the n/a's and most likely you don't have one.

As mentioned, there's a tag n the diff itself.

You could jack up the rear end and spin a wheel, if the other goes the same way it's a LSD.

Burnouts' 11's for the win.



_________________

1998 DL LTD in Sparkling Burgundy, daily, 302W, stereo, slow - 97.5rwkw
2006 BF GT-P in Ego, mods. 293rwkw - 12.427@109 - 0-1000m 24.838@221

Top
 Profile


 Post subject: Re: How to identify if a BA has an LSD!
Posted: Sun Jun 13, 2010 1:04 pm
Stock as a Rock
Offline

Age: 26

Posts: 144

Joined: 25th Apr 2010

Ride: 1992 Ford Eb Series 2

BOSXR8 wrote:
I just bought a BA XR6 over the weekend, i have a picture that has no reference to the question im about to ask but i thought you may like to see it! (yes its the BA that was on ebay)

ANYWAY how do i find out if it has an LSD? the a** swings out a little when i give it out of a corner but nothing like my eb xr6, so i wasnt sure. I am wondering if it should say anything on the plates or in the log books, or if there is a sticker like the older models some where on the diff?..

thanks!

Really only one way in my books, take it out for a little test run :P see if both spin
Top
 Profile


 Post subject: Re: How to identify if a BA has an LSD!
Posted: Sun Jun 13, 2010 3:47 pm
Getting Side Ways
Offline
User avatar

Age: 30

Posts: 1507

Joined: 14th Aug 2009

Gallery: 12 images

Ride: BA XT V8

Location: Gosnells, Perth
WA, Australia

yea just jack up the back an hav a look under it. i think on the drivers side theres a little tag that will say the ratio in big numbers then under that in smaller writing either LSD or standard diff. standard being open center.

i was also wondering if anyone else knew how to tell wether its a m78 or m86 as mine doesnt specify either way it just has som seriel numbers on it.



_________________

BA XT V8. Ice Mint. 18" Speedys. XR6T LSD. Full Pacemaker twin 2 1/2inch Stainless Steel system. Custom CAI. Black XR interior with white trimming. Powerbond underdrive kit 25%.
13.65@102mph. 2800 hi-Stall.
230RWKW@5250 rpm. 625NM.

Top
 Profile


 Post subject: Re: How to identify if a BA has an LSD!
Posted: Sat Jun 19, 2010 2:40 pm
Parts Gopher
Offline

Age: 41

Posts: 83

Joined: 15th Feb 2010

Ride: FG 2010 XR8 Ute

Location: Perth
WA, Australia

or just jack up both rear wheels and spin one tyre...if both tyres spin in the same direction you have LSD if one tyre spins one way and the other tyre spins the other way you dont have LSD

i had to order LSD in my ute from new coz the XR6 n/a didnt come with it. turbo and 8s did

sorry dat_mine i just read your post :roll:
Top
 Profile


 Post subject: Re: How to identify if a BA has an LSD!
Posted: Fri Jun 25, 2010 2:08 am
Getting Side Ways
Offline
User avatar

Posts: 649

Joined: 20th Mar 2005

Gallery: 2 images

Ring Ford Customer Service with your VIN number details etc. handy......
They will tell you from the build details of the car.
Top
 Profile


 Post subject: Re: How to identify if a BA has an LSD!
Posted: Fri Jun 25, 2010 12:16 pm
ACT Cruise Moderator
Offline
User avatar

Age: 36

Posts: 6275

Joined: 24th Nov 2004

Ride: '06 BF GT-P

Power: 293 rwkw

Location: Canberra
ACT, Australia

EB92 wrote:
Ring Ford Customer Service with your VIN number details etc. handy......
They will tell you from the build details of the car.


They of course can only tell you how it was built, won't help if it was changed by a previous owner. But yeah they're a great source of getting accurate info.



_________________

1998 DL LTD in Sparkling Burgundy, daily, 302W, stereo, slow - 97.5rwkw
2006 BF GT-P in Ego, mods. 293rwkw - 12.427@109 - 0-1000m 24.838@221

Top
