XR6 won't crank over - full battery



Page 1 of 1 [ 3 posts ]


 Post subject: XR6 won't crank over - full battery
Posted: Mon Feb 20, 2017 2:43 am
Fordmods Newbie
Offline

Posts: 1

Joined: 20th Feb 2017

Ride: 2007 Falcon XR6 BF MKII

Location: AUSTRALIND
WA, Australia

2007 XR6 FALCON BF MKII

1. Drove car into garage
2. Jacked up left, replaced wheel bearing and hub
3. Jacked up right, replaced wheel bearing and hub
4. Replaced courtesy lights fuse (may have done this with ignition turned to 1/3)
5. Won't start, tried different batteries, just a loud click coming from air manifold
6. Recently noticed a click coming from the P/W relay. How can I check a relay is faulty?
7. The car can be started by shorting the start motor
8. I've recently replaced combination switch so around the airbag and ignition has been tampered with but I was all good until the hub bearings (which took a bit of shaking) and fuse got changed
9. Crank Angle Sensor?
10. Faulty wiring to starter motor?
11. A mate used a multi-meter and confirmed start was getting enough power
12. roll it down the boat ramp?





Attachments:
ford.jpg [ 217.18 KiB | Viewed 16 times ]
Top
 Profile


 Post subject: Re: XR6 won't crank over - full battery
Posted: Mon Feb 20, 2017 3:33 pm
Getting Side Ways
Offline
User avatar

Age: 45

Posts: 861

Joined: 26th Nov 2007

Gallery: 20 images

Ride: XH Ute / AU3 V8 Wagon

Location: Bris-Vegas
QLD, Australia

Neutral start switch?
Solenoid wire fallen off starter? Does it run when you short the starter, or just crank over?
Is it in Park?
Is the Smartshield (?) light doing it's normal thing?

Best of luck. 8-)



_________________

Yes, I own a Ute. No, I won't help you move!

EL Wagon Build Thread http://www.fordmods.com/the-garage-f53/sooty72-s-ef-futura-wagon-long-term-project-t90025.html
XH Ute Thread http://www.fordmods.com/post1138970.html#p1138970

Top
 Profile


 Post subject: Re: XR6 won't crank over - full battery
Posted: Mon Feb 20, 2017 7:22 pm
Tyre Shredder
Offline
User avatar

Age: 34

Posts: 300

Joined: 24th Jun 2014

Gallery: 4 images

Ride: BA XR6 Turbo

Location: Jamestown
SA, Australia

maybe try giving the starter solenoid wire a little jiggle pull it off and slide it back on, have found my BA and Mothers BF gets a little oxide or something on it and looses connection give it a jiggle pull it off and slip it back on and all is good



_________________

Current Ride
BA XR6 Turbo, P3 Paint, BP Trim, Fully Stock Mods to Come!
1996 EF Falcon furura, White.
BA XR6 , P3 Paint, BG Trim, !
1995 EF XR6 The newest member of my ford family!

BLUE BLOOD
Previous Rides
1997 EL Falcon
1980 Ford Escort

Top
 Profile
