Fordmods Logo

Head done....now to the install???



Page 4 of 4 [ 59 posts ] Go to page Previous  1, 2, 3, 4


 Post subject: Re: Head done....now to the install???
Posted: Mon Mar 16, 2009 3:32 pm
Getting Side Ways
Offline
User avatar

Age: 28

Posts: 1456

Joined: 17th Apr 2008

Gallery: 3 images

Ride: VY Commodore Wagon Accli

Location: Bannockburn
VIC, Australia

What you have just said has actually helped me!

Although I couldn't undo that middle nut, I compressed the tensioner and then put it in! No wonder I have a timing chain rattle!!!!!!!!!

Betta fix that quick smart!



_________________

Pre AU Adapters for sale

Successful Trades with: John_XR6 (John_LS1), Private9, Schmee, Manari, Kyle_Bardell, Greenhorn (Boostedfalcon.net), FTG AUTO SALVAGE, EVL098, Gogetta, EFIII, Krytox, Blue, Smik-EL, TP351.

Top
 Profile


 Post subject: Re: Head done....now to the install???
Posted: Mon Mar 16, 2009 5:08 pm
Getting Side Ways
Offline

Posts: 6166

Joined: 8th May 2007

speedyED get that tensioner released before you drive the car again. Im surpised that you havnt snapped every chain guide by now !!! (unless you have already :shock: )

you will also have to remove the rocker cover and see if the tensioner is sitting against the chain guide properly
Top
 Profile


 Post subject: Re: Head done....now to the install???
Posted: Mon Mar 16, 2009 5:27 pm
Getting Side Ways
Offline
User avatar

Age: 45

Posts: 2688

Joined: 21st Oct 2007

Gallery: 28 images

Ride: NCII Fairlane + G220

Power: 143 rwkw

Location: Lake Macquarie
NSW, Australia

TROYMAN wrote:
thats good news mate. atleast you got another one thats the main thing..

i got a few pics just incase your not sure.
you need something like this to release the tensioner from its compressed position once it has been fitted..
its a long reach 3mm allen key with a 12mm tube.
Attachment:

to release it you need to fit the tensioner in the compressed position and fit the large outer part of the tensioner bolt.(with the centre bolt removed)
once its tight you insert the steel tube and allen key into the centre together and push in and rotate it anti clock wise and the tensioner will release puting tension back on the cam chain..
then you put the centre bolt back in and your back in buisnes......

this is what the complete tensioner looks like in its compressed position(no tension)
Attachment:


this is what it looks like in its released position..
Attachment:


this it what it looks like disassembled..
Attachment:


hope this helps???

You bet it helps! :D Thanks mate, you're an absolute legend.
I had the same problem as speedy, when I tried to undo the centre bolt, the whole kit'n'kaboodle came out. Will need to get hold of one of those special tools, to keep the outer bolt in position for future reference.
Cheers mate, you've saved my bacon yet again :mrgreen:



_________________

E-Series Fairlane/LTD? forums/post746329.html#746329
Mick's Garage forums/viewtopic.php?t=65504

Top
 Profile


 Post subject: Re: Head done....now to the install???
Posted: Mon Mar 16, 2009 5:48 pm
Getting Side Ways
Offline
User avatar

Age: 28

Posts: 1456

Joined: 17th Apr 2008

Gallery: 3 images

Ride: VY Commodore Wagon Accli

Location: Bannockburn
VIC, Australia

FordFairmont wrote:
speedyED get that tensioner released before you drive the car again. Im surpised that you havnt snapped every chain guide by now !!! (unless you have already :shock: )

you will also have to remove the rocker cover and see if the tensioner is sitting against the chain guide properly


I'll see, it could alway's be that it's the chain is tensioned but not enough, I'll find out for sure though.



_________________

Pre AU Adapters for sale

Successful Trades with: John_XR6 (John_LS1), Private9, Schmee, Manari, Kyle_Bardell, Greenhorn (Boostedfalcon.net), FTG AUTO SALVAGE, EVL098, Gogetta, EFIII, Krytox, Blue, Smik-EL, TP351.

Top
 Profile


 Post subject: Re: Head done....now to the install???
Posted: Mon Mar 16, 2009 6:22 pm
Getting Side Ways
Offline

Posts: 6166

Joined: 8th May 2007

NCIILANE wrote:
I had the same problem as speedy, when I tried to undo the centre bolt, the whole kit'n'kaboodle came out. Will need to get hold of one of those special tools, to keep the outer bolt in position for future reference.


try using multi grips to hold the outer bolt, whilst undoing the centre bolt
Top
 Profile


 Post subject: Re: Head done....now to the install???
Posted: Mon Mar 16, 2009 6:49 pm
Getting Side Ways
Offline
User avatar

Age: 45

Posts: 2688

Joined: 21st Oct 2007

Gallery: 28 images

Ride: NCII Fairlane + G220

Power: 143 rwkw

Location: Lake Macquarie
NSW, Australia

FordFairmont wrote:
NCIILANE wrote:
I had the same problem as speedy, when I tried to undo the centre bolt, the whole kit'n'kaboodle came out. Will need to get hold of one of those special tools, to keep the outer bolt in position for future reference.


try using multi grips to hold the outer bolt, whilst undoing the centre bolt

Yeah, I end up figuring it out and held the outer bolt with a set of stilsens. Thanks for all your help peoples, by this time tomorrow, there should be good news and it will all be up and running. :wink:



_________________

E-Series Fairlane/LTD? forums/post746329.html#746329
Mick's Garage forums/viewtopic.php?t=65504

Top
 Profile


 Post subject: Re: Head done....now to the install???
Posted: Mon Mar 16, 2009 6:58 pm
Getting Side Ways
Offline

Age: 31

Posts: 2337

Joined: 25th Apr 2008

Ride: Boxcar Love

Location: Brisbane
QLD, Australia

The ford tensioner idea sucks balls mkay.



_________________

Commodore australia's favorite car??? What a load of s**t

Top
 Profile


 Post subject: Re: Head done....now to the install???
Posted: Tue Mar 17, 2009 11:01 pm
Getting Side Ways
Offline
User avatar

Age: 45

Posts: 2688

Joined: 21st Oct 2007

Gallery: 28 images

Ride: NCII Fairlane + G220

Power: 143 rwkw

Location: Lake Macquarie
NSW, Australia

For those that have been following my dilema with with the timing chain tensioner, I found this nifty little tool when I was at supercheap this arvo picking up a long shaft allen key set.
It fit's the outer bolt perfectly....will need a little adjustment made to it for the final tightening of the bolt as it hits the step out section of the block where the power steering pump bolts up, because of it's square shape....nothing the dremel can't fix :P . Cost a whole $15.
Attachment:
IMG_1735 (Large).jpg
IMG_1735 (Large).jpg [ 64.29 KiB | Viewed 27 times ]

I feel a tech doco comin on :mrgreen:



_________________

E-Series Fairlane/LTD? forums/post746329.html#746329
Mick's Garage forums/viewtopic.php?t=65504

Top
 Profile


 Post subject: Re: Head done....now to the install???
Posted: Wed Mar 18, 2009 12:54 pm
Getting Side Ways
Offline
User avatar

Age: 28

Posts: 1456

Joined: 17th Apr 2008

Gallery: 3 images

Ride: VY Commodore Wagon Accli

Location: Bannockburn
VIC, Australia

NCIILANE wrote:
For those that have been following my dilema with with the timing chain tensioner, I found this nifty little tool when I was at supercheap this arvo picking up a long shaft allen key set.
It fit's the outer bolt perfectly....will need a little adjustment made to it for the final tightening of the bolt as it hits the step out section of the block where the power steering pump bolts up, because of it's square shape....nothing the dremel can't fix :P . Cost a whole $15.
Attachment:
IMG_1735 (Large).jpg

I feel a tech doco comin on :mrgreen:


You have my full attention!



_________________

Pre AU Adapters for sale

Successful Trades with: John_XR6 (John_LS1), Private9, Schmee, Manari, Kyle_Bardell, Greenhorn (Boostedfalcon.net), FTG AUTO SALVAGE, EVL098, Gogetta, EFIII, Krytox, Blue, Smik-EL, TP351.

Top
 Profile


 Post subject: Re: Head done....now to the install???
Posted: Wed Apr 01, 2009 11:05 pm
Getting Side Ways
Offline
User avatar

Posts: 807

Joined: 28th Oct 2008

Location: melburn
VIC, Australia

ok so seems to be a few heads in here that know about the tensioner...
i used this walkthrough to do mine - http://autofix.com.au/blog/archives/622

now i undid the outer bit, and it all came out sweet, then i put the allen key in to do the next part, twisted it clockwise, then wounter clockwise, but it basically came out before i realised what was happening...
now im left with this
have i done something wrong, or do i need to do anything further?
or am i ok to attempt installation once i do my head gasket?

it seemed too easy getting it out and has me worried lol
or is it getting it back in thats the problem?




_________________

XG Panelvan
mild engine, EL ECU & J3, HI6 & MSD coil

in the shed - .595" lift cam, GT4202, forged AU engine, ems 4424 ecu, glide & 5500 stall - next-bellhousing

XH ute daily - DOHC BA XR6 engine, T5, AU3 ECU, J3 chip, wideband & logger, ported BBM, 3" intake

Top
 Profile


 Post subject: Re: Head done....now to the install???
Posted: Thu Apr 02, 2009 10:42 am
Getting Side Ways
Offline
User avatar

Age: 45

Posts: 2688

Joined: 21st Oct 2007

Gallery: 28 images

Ride: NCII Fairlane + G220

Power: 143 rwkw

Location: Lake Macquarie
NSW, Australia

You've done well mate! That's how it should look when you remove it. That's in the closed poition, when you go to put it back in, you will feel it "pop out" when it is released to the open/tensioned position.
Don't ya just love the colour of the oil when it turns to mud :P
Mick



_________________

E-Series Fairlane/LTD? forums/post746329.html#746329
Mick's Garage forums/viewtopic.php?t=65504

Top
 Profile


 Post subject: Re: Head done....now to the install???
Posted: Thu Apr 02, 2009 10:54 am
Getting Side Ways
Offline
User avatar

Posts: 807

Joined: 28th Oct 2008

Location: melburn
VIC, Australia

lol phew!
i thought i f**k it up
i only had a 3mm allen key, didnt have the tube on the outside or anything, just stuck it in felt around and hoped for the best!
all in all getting the gear out for the head gasket change hasnt been as hard as i had thought, not saying its easy, but i had a much bigger idea of how hard it would be, but i know im going to hate the install!

and yes, muddy oil, yum yum lol




_________________

XG Panelvan
mild engine, EL ECU & J3, HI6 & MSD coil

in the shed - .595" lift cam, GT4202, forged AU engine, ems 4424 ecu, glide & 5500 stall - next-bellhousing

XH ute daily - DOHC BA XR6 engine, T5, AU3 ECU, J3 chip, wideband & logger, ported BBM, 3" intake

Top
 Profile


 Post subject: Re: Head done....now to the install???
Posted: Thu Apr 02, 2009 11:09 am
Getting Side Ways
Offline
User avatar

Age: 45

Posts: 2688

Joined: 21st Oct 2007

Gallery: 28 images

Ride: NCII Fairlane + G220

Power: 143 rwkw

Location: Lake Macquarie
NSW, Australia

When you come to fitting it back in, you will need a tube as described above to help release the tensioner. Another tip I will pass on is that there is a little oil filter located inside the outer bolt that needs to be removed so that you can fit a 12mm tube into the hole, then when it's all done just slip the filter back in before fitting the centre bolt.
Cheers,
Mick



_________________

E-Series Fairlane/LTD? forums/post746329.html#746329
Mick's Garage forums/viewtopic.php?t=65504

Top
 Profile


 Post subject: Re: Head done....now to the install???
Posted: Thu Apr 02, 2009 11:28 am
Getting Side Ways
Offline
User avatar

Posts: 807

Joined: 28th Oct 2008

Location: melburn
VIC, Australia

ahh yeah i was wondering how i would go about releasing it without it comiing out the hole lol.
cheers mate :D



_________________

XG Panelvan
mild engine, EL ECU & J3, HI6 & MSD coil

in the shed - .595" lift cam, GT4202, forged AU engine, ems 4424 ecu, glide & 5500 stall - next-bellhousing

XH ute daily - DOHC BA XR6 engine, T5, AU3 ECU, J3 chip, wideband & logger, ported BBM, 3" intake

Top
 Profile

Display posts from previous:
Sort by
 Page 4 of 4  [ 59 posts ]  Go to page Previous  1, 2, 3, 4

Who is online

Users browsing this forum: No registered users and 24 guests


You cannot post new topics in this forum
You cannot reply to topics in this forum
You cannot edit your posts in this forum
You cannot delete your posts in this forum
You cannot post attachments in this forum





It is currently Fri Dec 15, 2017 8:07 am All times are UTC + 11 hours





(c)2014 Total Web Solutions Australia - Australian Web Hosting and Domain Names
