 Post subject: AU2 XR8 Throttle Body on EL 165kw
Posted: Thu Jun 15, 2006 9:48 pm
Tyre Shredder
Offline
User avatar

Posts: 388

Joined: 5th Nov 2004

Gallery: 9 images

Location: Melb
VIC, Australia

Hi, what do I have to do to fit a AU2 XR8 throttle body up to my el v8?
I measured the throttle body, its 65mm on the side closest to the manifold, and the maf side is about 70mm. So i got no idea, im guessing its a 65mm throttle body? Is this what AU2 XR8's had? lol

I believe i have to drill the holes so I can fit up my eseries TPS, is there anything else?
I have read about changing voltages etc somewhere before, but i dont have a clue if i need to do this, or even how to do it.

Anyone able to give a few basic steps to fitting this thing up ?

Thanks guys,
Steve
Top
 Profile


Posted: Thu Jun 15, 2006 10:03 pm
Stock as a Rock
Offline
User avatar

Posts: 140

Joined: 12th May 2006

Gallery: 17 images

Location: Brisbane
QLD, Australia

Yes, it's an AU 65mm t/body. Just use a drill bit to widen the mounting holes as the bigger throttle bodies have a slightly wider mounting. Bolts are a slightly different size also.

You'll need to twist the TPS slightly until voltage is just under 1v. There's not much to it but if you are looking for more detail a search should reap plenty.
Top
 Profile


Posted: Thu Jun 15, 2006 10:10 pm
Tyre Shredder
Offline
User avatar

Posts: 388

Joined: 5th Nov 2004

Gallery: 9 images

Location: Melb
VIC, Australia

errrm thanks for the reply, but that voltage thing meany nothing to me!

How am i testing the voltage? lol
Top
 Profile


Posted: Fri Jun 16, 2006 12:25 pm
Tyre Shredder
Offline
User avatar

Posts: 388

Joined: 5th Nov 2004

Gallery: 9 images

Location: Melb
VIC, Australia

Please help :) *cry*
Top
 Profile


Posted: Fri Jun 16, 2006 1:51 pm
Getting Side Ways
Offline

Age: 34

Posts: 1204

Joined: 9th Nov 2004

Gallery: 11 images

Ride: EL Fairmont Ghia V8 Turbo

Power: 303 rwkw

Location: Melbourne
VIC, Australia

with the multimeter chuck the red lead in one of the wires (can't remember which one - it's either the green or brown i think) and earth the black one to the chasis of the car. You have to push the multimeter needle end thing down into the rubber casing of the tps plugs to get a reading from the wire. Loosen one of the screws on the tps and while at idle move it left and right until you get about 0.9 - 0.95 volts.
you have to use the tps off your old throttle body cause au's have single tps and e series have dual, one for ecu and one for trans.
You need to get the voltage for both of them right on and once you've done that then tighten the screws.
the hole will have to be elongated a fair bit, but its only necessary to do one, probably the one closest to the firewall.



_________________

EL Fairmont Ghia V8 Turbo 303rwkw

Top
 Profile


Posted: Fri Jun 16, 2006 1:53 pm
Tyre Shredder
Offline
User avatar

Posts: 388

Joined: 5th Nov 2004

Gallery: 9 images

Location: Melb
VIC, Australia

You rock mate. I knew you would save me.
I know how to use a mutimeter, just didnt know wtf i was poking it at lol.
Youve helped allot.
Im guessing im going to have to get the EGR spacer milled out a bit to suit this throttle body?
Top
 Profile


Posted: Fri Jun 16, 2006 1:57 pm
Getting Side Ways
Offline

Age: 34

Posts: 1204

Joined: 9th Nov 2004

Gallery: 11 images

Ride: EL Fairmont Ghia V8 Turbo

Power: 303 rwkw

Location: Melbourne
VIC, Australia

yeah eventually, but remember the maf is only 55mm so until you upgrade that it is still equivalent.....all in good time



_________________

EL Fairmont Ghia V8 Turbo 303rwkw

Top
 Profile


Posted: Fri Jun 16, 2006 2:07 pm
Getting Side Ways
Offline
User avatar

Age: 46

Posts: 3763

Joined: 25th Nov 2004

Gallery: 6 images

Ride: EFII 5.8 NOS TerroristGhia

Power: 274 rwkw

Location: Sydney Australia
NSW, Australia

Well done dave, You certainly paid a lot of attention when i taught you how to do that on the AFD
Brett



_________________

The Terrorist ED Retired due to RUST.
The TerrosistGhia, EF Ghia 351 EFI 5 Speed.
Millennium Falcon, Sleeper EL DOHC 6 Speed Manual EFI LPG
Member#1131
I didn't Vote for Multiculturalism, DID YOU!!!

Top
 Profile


Posted: Fri Jun 16, 2006 2:30 pm
Tyre Shredder
Offline
User avatar

Posts: 388

Joined: 5th Nov 2004

Gallery: 9 images

Location: Melb
VIC, Australia

offyaguts wrote:
yeah eventually, but remember the maf is only 55mm so until you upgrade that it is still equivalent.....all in good time


Yeah, i have a 70mm maf here to go on as well.

Thanks for you help dave. Hows your car going lately? (bastard) :lol:
Top
 Profile


Posted: Fri Jun 16, 2006 3:33 pm
Getting Side Ways
Offline

Age: 34

Posts: 1204

Joined: 9th Nov 2004

Gallery: 11 images

Ride: EL Fairmont Ghia V8 Turbo

Power: 303 rwkw

Location: Melbourne
VIC, Australia

haha, brett, learning from the best

what maf did you get? is it for 19 or 24lb injectors?

another 2 weeks and it should be 100%. Got the unichip (thanks again brett) which has to be installed and tuned, chasing up an egr spacer and will cut speed holes in the airbox....apart from that 180rwkw shouldn't be too far away at all.....can't wait. Also got underdrives to go on!!



_________________

EL Fairmont Ghia V8 Turbo 303rwkw

Top
 Profile


Posted: Fri Jun 16, 2006 5:15 pm
Tyre Shredder
Offline
User avatar

Posts: 388

Joined: 5th Nov 2004

Gallery: 9 images

Location: Melb
VIC, Australia

Im just putting my eseries plug on the au maf for the time being.

hmmm 180rwkw If im ever around your area again, ill give you a ring to take me for a drive :) :twisted:
