 Post subject: Re: V8 Manual Conversion
Posted: Fri Mar 26, 2010 1:58 am
Getting Side Ways
Offline
User avatar

Age: 35

Posts: 4285

Joined: 8th Dec 2004

Gallery: 25 images

Ride: EB2 Ghia,Mighty Boy,Eb1 Xr8 5spd

Location: ** In the Shed! **
VIC, Australia

There's an idea snap! But if you go to all that effort you should consider installing a billet retainer & set the preload correctly, so there is less chance of the box failing.

Cheers

ToranaGuy



_________________

I am the ToranaGuy!|74 Lh Torana Turbo|78 Hz PanelVan|86 Mighty Boy Ute|93 EB2 Ghia,GT Mockup,5spd,LPGI,Full Leather|2 x EB Xr8 5spd's|FS [VIC]: Wrecking - Eb XR8 - Parts available |Build Thread|Ebay Items - Ford Parts|

Top
 Profile


 Post subject: Re: V8 Manual Conversion
Posted: Fri Mar 26, 2010 2:28 pm
Technical Contributor
Offline
User avatar

Age: 53

Posts: 5589

Joined: 14th Jan 2005

Gallery: 10 images

Ride: 96 XH/97 EL

Location: South Coast
NSW, Australia

Well you would go over the whole box, change bearings, seals where needed.
It'd be a research exercise, comparing options and the likely $$$ involved and work needed as well.
As I say, be good to compare an early V8 T5 box with an I6 T5 to see how similar in the a*** they are.



_________________

96 XH Longreach 'S': LPG, Alarm, 3.23:1 LSD, Cruise, Trip Comp, ABS, Power Windows, Mid Series Dome Lt, Climate Ctrl
97 EL Futura S/W: LPG, Alarm, LED int Lts, Trip Comp, F/Lane Dome Lt, Climate Ctrl, T5 Conversion

Top
 Profile


 Post subject: Re: V8 Manual Conversion
Posted: Fri Mar 26, 2010 4:09 pm
Getting Side Ways
Offline
User avatar

Age: 45

Posts: 863

Joined: 26th Nov 2007

Gallery: 20 images

Ride: XH Ute / AU3 V8 Wagon

Location: Bris-Vegas
QLD, Australia

I have the T5 manual in PDF form if anyone wants it. You can probably find it online if you look hard enough.
Also, look for a book called "How to rebuild and modify your manual transmission"
Attachment:
motobooks_2096_106082381.jpg [ 34.03 KiB | Viewed 37 times ]

It covers the basics of manual transmissions, plus it has a full step by step rebuild of a T5. A good read, and very helpful. :D



_________________

Yes, I own a Ute. No, I won't help you move!

EL Wagon Build Thread http://www.fordmods.com/the-garage-f53/sooty72-s-ef-futura-wagon-long-term-project-t90025.html
XH Ute Thread http://www.fordmods.com/post1138970.html#p1138970

Last edited by sooty72 on Mon Apr 19, 2010 9:26 am, edited 1 time in total.

Top
 Profile


 Post subject: Re: V8 Manual Conversion
Posted: Wed Apr 07, 2010 11:52 pm
Getting Side Ways
Offline
User avatar

Age: 35

Posts: 4285

Joined: 8th Dec 2004

Gallery: 25 images

Ride: EB2 Ghia,Mighty Boy,Eb1 Xr8 5spd

Location: ** In the Shed! **
VIC, Australia

I've had a good long read over that manual, many thanks for sending it dude, and i feel that if i borrow a couple of tools from my g/f's dad i could do a good rebuild on a T5 now.

I changed the clutch & throw out fork in my Eb Ghia I6 T5 setup a couple of days ago, and man, the box is shifting really good. I'd love a short shifter tho.... I put in a PBR HD clutch kit, and it doesn't feel all that heavy duty, but it grips really well. I've got to run it in a little more, then i will see what it's like pulling my tandem trailer.

Cheers

ToranaGuy



_________________

I am the ToranaGuy!|74 Lh Torana Turbo|78 Hz PanelVan|86 Mighty Boy Ute|93 EB2 Ghia,GT Mockup,5spd,LPGI,Full Leather|2 x EB Xr8 5spd's|FS [VIC]: Wrecking - Eb XR8 - Parts available |Build Thread|Ebay Items - Ford Parts|

Top
 Profile


 Post subject: Re: V8 Manual Conversion
Posted: Thu Apr 08, 2010 1:39 am
Getting Side Ways
Offline

Age: 29

Posts: 4182

Joined: 30th May 2005

Ride: 1993 EB XR8

Location: BrisVegas
QLD, Australia

ToranaGuy wrote:
XFWAGON wrote:
The Au's got the T5Z's, the previous XR8's just got a normal WC T5.


Interesting. Thanks for that info.

Cheers

ToranaGuy


IIRC only the 200/220kw got the T5Z. My 185kw has a basic Tremec T5. Not T5Z



_________________

ILL60 - EF XR8, Sunroof, Ticky Kit, 19x8.5/19x11 TE37's, 347, AFr185's, TFS BoxRcustom converter, Hurst Quarterstick, huge billet cam.

51TER - DL LTD. Stock.

Top
 Profile


 Post subject: Re: V8 Manual Conversion
Posted: Thu Apr 08, 2010 8:31 pm
Getting Side Ways
Offline
User avatar

Age: 31

Posts: 2450

Joined: 5th Nov 2004

Gallery: 1 images

Ride: NL V8 Fairlane

Location: Sydney
NSW, Australia

Hmm, I am pretty sure Mal Wood told me that the EF/EL V8s had T5Zs behind them. Well at least that is what I bought to replace mine! To be confirmed!



_________________

There are 10 types of people in this world.
Those who know binary and those who don't.

Top
 Profile


 Post subject: Re: V8 Manual Conversion
Posted: Sat Apr 10, 2010 7:08 pm
Getting Side Ways
Offline
User avatar

Age: 31

Posts: 2450

Joined: 5th Nov 2004

Gallery: 1 images

Ride: NL V8 Fairlane

Location: Sydney
NSW, Australia

I'm wrong. E series all had WC T5s.

Main way to tell the difference from a normal T5 is that the T5Z input shaft uses a tapered needle roller bearing.



_________________

There are 10 types of people in this world.
Those who know binary and those who don't.

Top
 Profile


 Post subject: Re: V8 Manual Conversion
Posted: Sat Apr 10, 2010 10:20 pm
Getting Side Ways
Offline
User avatar

Age: 35

Posts: 4285

Joined: 8th Dec 2004

Gallery: 25 images

Ride: EB2 Ghia,Mighty Boy,Eb1 Xr8 5spd

Location: ** In the Shed! **
VIC, Australia

I thought the WC T5 come in the EB series 2?

Cheers

ToranaGuy



_________________

I am the ToranaGuy!|74 Lh Torana Turbo|78 Hz PanelVan|86 Mighty Boy Ute|93 EB2 Ghia,GT Mockup,5spd,LPGI,Full Leather|2 x EB Xr8 5spd's|FS [VIC]: Wrecking - Eb XR8 - Parts available |Build Thread|Ebay Items - Ford Parts|

Top
 Profile


 Post subject: Re: V8 Manual Conversion
Posted: Sat Apr 10, 2010 11:42 pm
Technical Contributor
Offline
User avatar

Age: 53

Posts: 5589

Joined: 14th Jan 2005

Gallery: 10 images

Ride: 96 XH/97 EL

Location: South Coast
NSW, Australia

One Drone wrote:
I'm wrong. E series all had WC T5s. Main way to tell the difference from a normal T5 is that the T5Z input shaft uses a tapered needle roller bearing.

I'd say we're assuming V8's here.
ToranaGuy wrote:
I thought the WC T5 come in the EB series 2?
I6's they did.
Thing is, all WC I6 T5's had a tapered bearing on the mainshaft behind the input shaft.
All I6 WC and non WC boxes had a tapered roller for the input shaft itself.



_________________

96 XH Longreach 'S': LPG, Alarm, 3.23:1 LSD, Cruise, Trip Comp, ABS, Power Windows, Mid Series Dome Lt, Climate Ctrl
97 EL Futura S/W: LPG, Alarm, LED int Lts, Trip Comp, F/Lane Dome Lt, Climate Ctrl, T5 Conversion

Top
 Profile


 Post subject: Re: V8 Manual Conversion
Posted: Sun Apr 11, 2010 12:09 am
Getting Side Ways
Offline
User avatar

Age: 31

Posts: 2450

Joined: 5th Nov 2004

Gallery: 1 images

Ride: NL V8 Fairlane

Location: Sydney
NSW, Australia

Yep that's what I meant snap. Cheers



_________________

There are 10 types of people in this world.
Those who know binary and those who don't.

Top
 Profile


 Post subject: Re: V8 Manual Conversion
Posted: Mon Apr 12, 2010 10:59 pm
EFI Guru
Offline

Age: 52

Posts: 4289

Joined: 5th Nov 2004

Gallery: 28 images

Ride: 351 Vogue,XH 5.0,'17 5.0 Stang

Location: Perth
WA, Australia

ToranaGuy wrote:
Sturmovik wrote:
Pretty sure only the Sprint and GT had different ratios.


Really?

Cheers

ToranaGuy


That's correct, GT/Sprint T5's had a 3.35 1st gear and carbon fibre rings and tapered rollers and use auto trans fluid. Std T5's still use gear oil with brass rings.
Interestingly the original U.S. Z-type has a 2.95 1st gear which also makes it stronger than our 3.35 variant.
Top
 Profile


 Post subject: Re: V8 Manual Conversion
Posted: Sun Apr 18, 2010 5:21 pm
Getting Side Ways
Offline
User avatar

Age: 29

Posts: 1700

Joined: 24th Nov 2005

Gallery: 12 images

Ride: DCII LTD V8

Location: Dunedin
New Zealand

XR9UTE wrote:
ToranaGuy wrote:
Sturmovik wrote:
Pretty sure only the Sprint and GT had different ratios.


Really?

Cheers

ToranaGuy


That's correct, GT/Sprint T5's had a 3.35 1st gear and carbon fibre rings and tapered rollers and use auto trans fluid. Std T5's still use gear oil with brass rings.
Interestingly the original U.S. Z-type has a 2.95 1st gear which also makes it stronger than our 3.35 variant.


When i ordered the parts for my T5Z, they only had the one option, original spec gear. 2.95 input, all pocket bearings, carbon fibre rings, twin brass rings for reverse/fifth.

The US T5's never used the input shaft that the Falcons got, US had slightly shorter ones. So the 2.95 T5Z input is a Falcon exclusive.

They are basically Cobra T5z's with the Falcon length input shaft.



_________________

1993 LTD V8 Oregon 5 speed "click me"

Trick Flow Heads/Cam/Intake, Crane Ignition, T5Z Trans.

Top
 Profile


 Post subject: Re: V8 Manual Conversion
Posted: Sun Apr 18, 2010 5:26 pm
Getting Side Ways
Offline
User avatar

Age: 29

Posts: 1700

Joined: 24th Nov 2005

Gallery: 12 images

Ride: DCII LTD V8

Location: Dunedin
New Zealand

One Drone wrote:
I'm wrong. E series all had WC T5s.

Main way to tell the difference from a normal T5 is that the T5Z input shaft uses a tapered needle roller bearing.



It's actually a tapered pocket bearing on the input. The gears have the needle rollers underneath them.

Main way to tell is the Input will have 24 teeth. (24 teeth = T5Z exclusive, 2.95 input shaft)



_________________

1993 LTD V8 Oregon 5 speed "click me"

Trick Flow Heads/Cam/Intake, Crane Ignition, T5Z Trans.

Top
 Profile


 Post subject: Re: V8 Manual Conversion
Posted: Sun Apr 18, 2010 7:00 pm
EFI Guru
Offline

Age: 52

Posts: 4289

Joined: 5th Nov 2004

Gallery: 28 images

Ride: 351 Vogue,XH 5.0,'17 5.0 Stang

Location: Perth
WA, Australia

I assume you mean the long input, 2.95 was a Falcon exclusive? I believe it's actually just the '94-'95 stang gearbox which has the 0.67" longer input than the '86-'93 type?
My mate has the Z-type 2.95 gearbox in his Capri that he bought new straight out of the Ford racing catalog #M-7003-Z...2.95 1st,short input.
Most likely the 2.95 1st was used in the AU which explains why you had no option of the 3.35 1st of the earlier cars which of course would have been obsolete 5mins after they were sold. :roll:
Top
 Profile


 Post subject: Re: V8 Manual Conversion
Posted: Sun Apr 18, 2010 8:20 pm
Getting Side Ways
Offline

Age: 36

Posts: 508

Joined: 28th Feb 2009

Gallery: 9 images

Ride: Ed v8 fairmont wagon, wr450f

Power: 137 rwkw

just throw few idea's into this,my new car i got yesterday run's a 6 cylinder t5 behind its 5L by using a T10 bellhousing redrilled to suit t5 from mal wood and converted to cable instead of hydraulic clutch..

phill
