 Post subject: Lowered cars. Where to measure from?
Posted: Mon Jan 08, 2007 6:35 pm
Getting Side Ways
Offline

Posts: 6913

Joined: 6th Nov 2004

Gallery: 4 images

Ride: BF XR6, BF XT Wagon

Power: 197 rwkw

Location: Perth
WA, Australia

To determine if a car is level after being lowered and consider it having a 1/2 tank of fuel where would you measure it from?

On level ground to the sills just in front of rear wheels and just behind front wheels.

From top of the tyre to the wheel arch.

Any other measuring points?


After lowering mine I measure from the wheel arches and the front is 30mm from the tyre to the wheel arch and the rear is 5-10mm. The rear side with fuel tank is lower than the other rear side.

Measuring from the sills to the ground they are even all round.

The front being higher from the tyre to the wheel arch makes it look a bit funny but the car is level according to the sills method of measuring.



_________________

EL XR8
Timmeh banned himself from being a moderator.

Top
 Profile


Posted: Mon Jan 08, 2007 9:20 pm
Getting Side Ways
Offline
User avatar

Age: 49

Posts: 6467

Joined: 18th Dec 2006

Ride: 93 ED sedan

Power: 161 rwkw

Location: Rockhampton
QLD, Australia

When you fit lower springs, measure before you fit, ( from bottom of rim, through the centre of wheel, so you know your square, up to the bottom edge of the guard.). The springs can be marked, RHF, LHF, RHR, LHR, which is self explanetry. On the OE springs, the one with the White stripe of paint went on the right, ( remember white is right). This stripe was next to the other stripe denoting the springs application.
To check if its level now, all you could do is measure it at the sills on a dead level surface.



_________________

http://youtu.be/jJTh9F3Vgg0

Top
 Profile


Posted: Mon Jan 08, 2007 9:22 pm
Getting Side Ways
Offline

Age: 35

Posts: 516

Joined: 3rd Dec 2004

Ride: SZ Titanium & ZG Fairlane

Location: Roxby Downs
SA, Australia

The actual legal measurement in SA are taken from the centre of the hub to the guard. Eg. from the centre of your mag up to the top arch of the guard. Dunno if that helps but anyway . . .



_________________

F6 Rspec #139 - Stock Car Racing

Top
 Profile


Posted: Tue Jan 09, 2007 2:35 pm
Fordmods Newbie
Offline

Posts: 11

Joined: 5th Nov 2006

Location: melb
VIC, Australia

thats right make sure your on level ground it hard that way better lookin on ebay to find a set already done
Top
 Profile


Posted: Tue Jan 09, 2007 2:36 pm
Fordmods Newbie
Offline

Posts: 11

Joined: 5th Nov 2006

Location: melb
VIC, Australia

in melb it is taken from the lowest point of your car so even if you have a screw hanging down they take from there sucks
Top
 Profile


Posted: Tue Jan 09, 2007 2:44 pm
Getting Side Ways
Offline
User avatar

Age: 31

Posts: 557

Joined: 20th Aug 2006

Gallery: 4 images

Ride: EF

Location: Keilor, Melbourne
VIC, Australia

yeah melb is lowest point, doesnt matter what, or where it is.
Usually in falcons its the first muffler, just before the diff.

Mine was 70mm from ground....never got pulled over..surprise really lol



_________________

<img src="http://i29.photobucket.com/albums/c260/demoniquekryes/Bothcars1.jpg" alt="Photobucket - Video and Image Hosting"><br><br>

Top
 Profile


Posted: Tue Jan 09, 2007 3:19 pm
Getting Side Ways
Offline
User avatar

Age: 44

Posts: 10126

Joined: 5th Nov 2004

Gallery: 4 images

Ride: EF Gli Ghia, XP Fairmont

Location: Perth
WA, Australia

here you go Timmeh

http://www.dpi.wa.gov.au/mediaFiles/lic_IB-116A.pdf

"Ground clearance of a vehicle must not be less than 100mm with the vehicle loaded or all seating positions occupied"

So that means they will take the lowest point of the car and measure from there, whether that be a suspension point, centre of diff etc!



_________________

Owning 1 of 67612 EF GLi Sedans made
FACT: "Chuck Norris owns the greatest Poker Face of all-time. It helped him win the 1983 World Series of Poker despite him holding just a Joker, a Get out of Jail Free Monopoly card, a 2 of clubs, 7 of spades and a green #4 card from the game Uno."

Top
 Profile


Posted: Tue Jan 09, 2007 6:05 pm
Getting Side Ways
Offline

Posts: 6913

Joined: 6th Nov 2004

Gallery: 4 images

Ride: BF XR6, BF XT Wagon

Power: 197 rwkw

Location: Perth
WA, Australia

Cheers guys but I'm not worried about the legality as the car is still a legal height.
Just was concerned about the car being level all round.

Its all sorted now anyway so thanks guys.



_________________

EL XR8
Timmeh banned himself from being a moderator.

Top
 Profile


Posted: Tue Jan 09, 2007 6:41 pm
Getting Side Ways
Offline
User avatar

Age: 31

Posts: 686

Joined: 3rd Apr 2005

Gallery: 16 images

Ride: ed fairmont ghia, ed gli

Location: mildura
VIC, Australia

why worry if its out a mm or two, if it looks level an your happy with the out come, so be it



_________________

I LOVE MY DOG

Top
 Profile


Posted: Tue Jan 09, 2007 7:36 pm
Getting Side Ways
Offline

Posts: 6913

Joined: 6th Nov 2004

Gallery: 4 images

Ride: BF XR6, BF XT Wagon

Power: 197 rwkw

Location: Perth
WA, Australia

It was out by more than 1mm or 2mm. It was 10-15mm and was noticeable.

But not for long its going to get fixed shortly.



_________________

EL XR8
Timmeh banned himself from being a moderator.

Top
 Profile


Posted: Tue Jan 09, 2007 10:03 pm
Getting Side Ways
Offline
User avatar

Age: 31

Posts: 686

Joined: 3rd Apr 2005

Gallery: 16 images

Ride: ed fairmont ghia, ed gli

Location: mildura
VIC, Australia

well still if it looks level an your happy then dont worry about what mm it is out,


an once its fixed be sure to post up some pics :wink:



_________________

I LOVE MY DOG

Top
 Profile


Posted: Tue Jan 09, 2007 11:38 pm
Getting Side Ways
Offline

Posts: 6913

Joined: 6th Nov 2004

Gallery: 4 images

Ride: BF XR6, BF XT Wagon

Power: 197 rwkw

Location: Perth
WA, Australia

Didn't look level that was the problem.

And don't worry I'll be showing off my car when its all fixed. :D



_________________

EL XR8
Timmeh banned himself from being a moderator.

Top
 Profile


Posted: Thu Jan 25, 2007 9:51 pm
Getting Side Ways
Offline

Posts: 632

Joined: 20th Jan 2007

Gallery: 6 images

Ride: el xr8

Location: bidwill
NSW, Australia

hi i had an xf i lowered i took it 4 a blue slip and the mechanic measured the height from the chassis 2 ground and level ground



_________________

i smell bad even when fm members drive past lol.

Top
 Profile


Posted: Fri Jan 26, 2007 9:42 am
Getting Side Ways
Offline
User avatar

Age: 40

Posts: 1780

Joined: 31st Jan 2005

Gallery: 10 images

Ride: 07 BF mk2 E-gas wagon + eb 5.0

Power: 174 rwkw

Location: Adelaide
SA, Australia

don't worry about it sitting a bit lower at the rear. thats a good look imo. i'd rather have it sitting down a bit than sitting up a bit. have attached a pic of my car. sits down a bit at back but thats the setup i like.

also regarding how to measure the hieght. kings springs give their measurements as centre of hub to guard. pedders are bottom of rim to guard. most common seems to be the kings method, including s.a. transport. (regency)





Attachments:
polished.jpg [ 184.48 KiB | Viewed 29 times ]



_________________

eb v8: low loud and fast. just how a v8 should be. i guess the big question is, is it fast enough...

Top
 Profile


 Post subject: ok
Posted: Sat Feb 03, 2007 3:56 am
Stock as a Rock
Offline

Posts: 165

Joined: 2nd Feb 2007

Ride: Ford AU series 2 Wagon

Location: melbourne
VIC, Australia

u should measure from the top of the wheel arch and if lowered correctly front and rear wheel arches shoulld be the same distance from the ground.



_________________

wagoff

Top
 Profile
